Siemens
3RT2045-3XF40-0LA2
SIRIUS 3RT Contactor
New, original packaging In stock
$193.90
Product price excludes international shipping.
Product details
Product Details: * 3-pole contactor * Rated operational current: 80 A * Motor rating: 37 kW at 400 V AC * Coil voltage: 110 V DC * Auxiliary contacts: 1 NO + 1 NC * Integrated varistor * Main circuit: screw terminals * Control / auxiliary circuit: spring-loaded terminals * Frame size: S3 * Suitable for DIN rail or screw mounting
The photographs show this part in its original sealed packaging, with the manufacturer label, exactly as the stock is held. Nothing has been opened to photograph it, so the carton seal and the label can both be checked against what arrives.
Specifications
| Manufacturer | Siemens |
|---|---|
| Part number | 3RT2045-3XF40-0LA2 |
| Rated operational current | 80 A |
| Motor rating | 37 kW at 400 V AC |
| Coil voltage | 110 V DC |
| Auxiliary contacts | 1 NO + 1 NC |
| Main circuit | screw terminals |
| Control / auxiliary circuit | spring-loaded terminals |
| Frame size | S3 |
| Weight | 1.817 kg |
| Dimensions | 15.2 × 7.0 × 14.0 cm |
Shipping & ordering
Send the request without paying anything. We confirm the international freight for your address and send you a final total; payment is only asked for once you have approved that total.
Stock is not reserved by sending a request, so availability is re-checked when the freight is confirmed.
Technical specifications
| Brand | Siemens |
|---|---|
| Model number | 3RT2045-3XF40-0LA2 |
| Condition | New, original packaging |
| Availability | In stock |
| Rated operational current | 80 A |
| Motor rating | 37 kW at 400 V AC |
| Coil voltage | 110 V DC |
| Auxiliary contacts | 1 NO + 1 NC |
| Main circuit | screw terminals |
| Control / auxiliary circuit | spring-loaded terminals |
| Frame size | S3 |
