ABLS1A24031

Product Details: * Model: ABLS1A24031 * Brand: Schneider Electric * Series: Modicon Power Supply * Product Type: Regulated Switch Mode Power Supply * Variant: Optimized * Rated Input Voltage: 100-240 VAC, Single Phase * DC Input Range: 140-340 VDC * Output Voltage: 24 VDC * Output Voltage Adjustment: 21.6-26.4 VDC * Output Current: 3.13 A * Rated Power: 75 W * Input Frequency: 50/60 Hz * Protection: Overload, Short Circuit, Overtemperature and Overvoltage Protection * Output Terminals: 4 * Status Indicator: Green LED * Mounting: 35 mm DIN Rail * Protection Rating: IP20 * Operating Temperature: up to 70°C with derating

Schneider Electric officially identifies ABLS1A24031 as a 75 W regulated industrial power supply with 100-240 VAC input and 24 VDC / 3.13 A output.

The photographs show this part in its original sealed packaging, with the manufacturer label, exactly as the stock is held. Nothing has been opened to photograph it, so the carton seal and the label can both be checked against what arrives.

Send the request without paying anything. We confirm the international freight for your address and send you a final total; payment is only asked for once you have approved that total.

Stock is not reserved by sending a request, so availability is re-checked when the freight is confirmed.
