Eaton
DILM9-10C(24VDC)
Contactor
New, original packaging In stock
$79.00
Product price excludes international shipping.
Product details
Product Details: * Model: DILM9-10C(24VDC) * Alternate Marking: XTCE009BC10 * Brand: Eaton * Series: Moeller DILM * Product Type: Contactor * Coil Voltage: 24 VDC * Number of Poles: 3 * Main Contacts: 3 NO * Auxiliary Contacts: 1 NO * Motor Rating: 4 kW at 380/400 V * Operation Type: DC Operated * Connection Type: Screw Terminals * Utilization Categories: AC-1 / AC-3 / AC-4 * Frame Size: FS1 * Mechanical Life: Up to 10,000,000 Operations * Mounting: DIN Rail / Screw Mounting * Certifications: CE, UL, CSA, IEC/EN 60947-4-1
Eaton’s official specification for the corresponding DILM9-10(24VDC) model lists a 3-pole contactor, 4 kW at 380/400 V, 1 NO auxiliary contact, 24 VDC coil, DC operation, and screw terminals.
The photographs show this part in its original sealed packaging, with the manufacturer label, exactly as the stock is held. Nothing has been opened to photograph it, so the carton seal and the label can both be checked against what arrives.
Specifications
| Manufacturer | Eaton |
|---|---|
| Part number | DILM9-10C(24VDC) |
| Alternate Marking | XTCE009BC10 |
| Series | Moeller DILM |
| Product Type | Contactor |
| Coil Voltage | 24 VDC |
| Number of Poles | 3 |
| Main Contacts | 3 NO |
| Auxiliary Contacts | 1 NO |
| Motor Rating | 4 kW at 380/400 V |
| Operation Type | DC Operated |
| Connection Type | Screw Terminals |
| Utilization Categories | AC-1 / AC-3 / AC-4 |
| Frame Size | FS1 |
| Weight | 0.296 kg |
| Dimensions | 7.50 × 4.50 × 6.80 cm |
Shipping & ordering
Send the request without paying anything. We confirm the international freight for your address and send you a final total; payment is only asked for once you have approved that total.
Stock is not reserved by sending a request, so availability is re-checked when the freight is confirmed.
Technical specifications
| Brand | Eaton |
|---|---|
| Model number | DILM9-10C(24VDC) |
| Condition | New, original packaging |
| Availability | In stock |
| Alternate Marking | XTCE009BC10 |
| Series | Moeller DILM |
| Product Type | Contactor |
| Coil Voltage | 24 VDC |
| Number of Poles | 3 |
| Main Contacts | 3 NO |
| Auxiliary Contacts | 1 NO |
| Motor Rating | 4 kW at 380/400 V |
| Operation Type | DC Operated |
| Connection Type | Screw Terminals |
| Utilization Categories | AC-1 / AC-3 / AC-4 |
| Frame Size | FS1 |
