Schneider Electric
METSEDM6200HCL10RS
Digital Power / Multifunction Meter
New, original packaging In stock
$223.73
Product price excludes international shipping.
Product details
Product Details:
Brand: Schneider Electric Model: METSEDM6200HCL10RS Series: EasyLogic DM6200H Product Type: Digital Power / Multifunction Meter
EasyLogic DM6200H multifunction digital meter for electrical parameter monitoring in panels, motors and distribution systems. Measures voltage, current, frequency, power factor, phase angle and network unbalance. Equipped with RS-485 communication and front display. Voltage: 48–277 VAC ±10% Frequency: 50/60 Hz ±5 Hz Communication: RS-485 Accuracy Class: 1.0 Protection: IP51 front / IP30 body
Official Dimensions (L × W × H): 6.2 × 9.6 × 9.6 cm (Panel depth 4.9 cm + front projection 1.3 cm) Official Weight: 0.300 kg Official Package Dimensions (L × W × H): 10.2 × 8.7 × 10.6 cm Package Weight: 0.347 kg
The photographs show this part in its original sealed packaging, with the manufacturer label, exactly as the stock is held. Nothing has been opened to photograph it, so the carton seal and the label can both be checked against what arrives.
Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Part number | METSEDM6200HCL10RS |
| Electric Model | METSEDM6200HCL10RS |
| Series | EasyLogic DM6200H |
| Voltage | 48–277 VAC ±10% |
| Frequency | 50/60 Hz ±5 |
| Hz Communication | RS-485 |
| Accuracy Class | 1.0 |
| Official Weight | 0.300 kg Official Package Dimensions (L × W × H): 10.2 × 8.7 × 10.6 cm |
| Package Weight | 0.347 kg |
| Weight | 0.300 kg |
| Dimensions | 6.2 × 9.6 × 9.6 cm |
Shipping & ordering
Send the request without paying anything. We confirm the international freight for your address and send you a final total; payment is only asked for once you have approved that total.
Stock is not reserved by sending a request, so availability is re-checked when the freight is confirmed.
Technical specifications
| Brand | Schneider Electric |
|---|---|
| Model number | METSEDM6200HCL10RS |
| Condition | New, original packaging |
| Availability | In stock |
| Electric Model | METSEDM6200HCL10RS |
| Series | EasyLogic DM6200H |
| Voltage | 48–277 VAC ±10% |
| Frequency | 50/60 Hz ±5 |
| Hz Communication | RS-485 |
| Accuracy Class | 1.0 |
| Official Weight | 0.300 kg Official Package Dimensions (L × W × H): 10.2 × 8.7 × 10.6 cm |
| Package Weight | 0.347 kg |
