MTN6500-0101

Product Details:

Model: MTN6500-0101

Series: SpaceLogic KNX

The Schneider Electric MTN65000101 is a SpaceLogic KNX DIN rail coupler designed for the logical connection and electrical isolation of KNX lines and areas. It supports KNX Secure and is suitable for commercial and residential building automation applications.  Main Specifications: Bus Type: KNX Mounting: DIN Rail Module Width: 1 × 18 mm module Power Supply Input Current: 5 mA Communication Protocol: KNX / KNX Long Frame / KNX Data Security Control: 2 Push-buttons Local Indication: 3 LEDs KNX Secure: Supported Protection Rating: IP20 Operating Temperature: -5°C to +45°C Storage Temperature: -25°C to +70°C Relative Humidity: 5–93%  Official Package Dimensions: 9.5 × 7.0 × 6.0 cm (L × W × H)

The photographs show this part in its original sealed packaging, with the manufacturer label, exactly as the stock is held. Nothing has been opened to photograph it, so the carton seal and the label can both be checked against what arrives.

Send the request without paying anything. We confirm the international freight for your address and send you a final total; payment is only asked for once you have approved that total.

Stock is not reserved by sending a request, so availability is re-checked when the freight is confirmed.
