S8VS-24024/ED2

Product Details: The OMRON S8VS-24024/ED2 is a 240 W industrial switch mode power supply designed for control panels, automation equipment, PLC systems and industrial machinery. The S8VS-24024 platform provides a regulated 24 VDC output at 10 A and supports 100–240 VAC input. It uses screw terminal connections and is designed for DIN-rail mounting.  Main Specifications: Rated Power: 240 W Output Voltage: 24 VDC Output Current: 10 A Rated Input Voltage: 100–240 VAC Allowable Input Range: 85–264 VAC / 80–370 VDC Frequency: 50/60 Hz Connection: Screw Terminal Block Mounting: DIN Rail Construction: Covered Type Operating Temperature: -10°C to +60°C Storage Temperature: -25°C to +65°C

The photographs show this part in its original sealed packaging, with the manufacturer label, exactly as the stock is held. Nothing has been opened to photograph it, so the carton seal and the label can both be checked against what arrives.

Send the request without paying anything. We confirm the international freight for your address and send you a final total; payment is only asked for once you have approved that total.

Stock is not reserved by sending a request, so availability is re-checked when the freight is confirmed.
