UB500-18GM75-E5-V15

Product Details: * Model: UB500-18GM75-E5-V15 * Part No.: 133053 * Brand: PEPPERL+FUCHS * Product Type: Ultrasonic Sensor * Sensor Principle: Ultrasonic * Sensing Range: 30-500 mm * Adjustment Range: 50-500 mm * Dead Band: 0-30 mm * Standard Target Plate: 100 × 100 mm * Transducer Frequency: Approx. 380 kHz * Response Delay: Approx. 50 ms * Operating Voltage: 10-30 VDC * No-Load Supply Current: ≤50 mA * Output Type: 1 PNP Switching Output * Output Function: Normally Open / Normally Closed, Programmable * Rated Operating Current: 200 mA * Switching Frequency: Max. 8 Hz * Repeat Accuracy: ≤1% * Range Hysteresis: 1% of Set Operating Distance * Temperature Compensation: Yes * Synchronization: Supported * Program Input: Yes * Connection: M12 × 1, 5-Pin Connector * Thread Size: M18 × 1 * Housing Material: Nickel-Plated Brass * Protection Rating: IP67 * Operating Temperature: -25°C to +70°C * Storage Temperature: -40°C to +85°C

PEPPERL+FUCHS officially specifies the UB500-18GM75-E5-V15 as a programmable ultrasonic sensor with a 30-500 mm sensing range, 10-30 VDC supply and PNP switching output.

The photographs show this part in its original sealed packaging, with the manufacturer label, exactly as the stock is held. Nothing has been opened to photograph it, so the carton seal and the label can both be checked against what arrives.

Send the request without paying anything. We confirm the international freight for your address and send you a final total; payment is only asked for once you have approved that total.

Stock is not reserved by sending a request, so availability is re-checked when the freight is confirmed.
